I DP shank cutter Z2+1 I DP shank cutter Z3+1

I Cutting 2.0 I Cutting 2.0

S Your benefits at a glance:

• Tear-free edges on the top coat • Ideally suitable for zero joint gaps
• No tearing with transverse and laser edge banding technology
edge banding • Extremely long tool life
• No multiple machining • Large variety of materials
L 1 Application: For sizing, grooving, jointing, rebating; very precise
shank tolerances, therefore suitable for shrink
clamping (recommended)
L 2
Material: Panel material with and without coating
L 3
Machine: Stationary machines
D Design: Tool body in steel; DP knives with axial angle and divided cut
Tooth: DP; L3* = positive spin, cutting edge is pulling up

Clockwise rotating tools with shank 20mm and threaded bore hole M6

D L2 L1 L3* Shank Rhs/ BH Z Order No. Price
mm mm mm mm mm lhs mm [PG 03]
16 29 100 5 20 rhs 3,5 2+1 10227906
16 37 105 5 20 rhs 3,5 2+1 10223148
20 22 90 5 20 rhs 3,5 2+1 10241978
20 30,5 100 5 20 rhs 4,0 2+1 10227843
20 39 110 5,3 20 rhs 4,0 2+1 10227839
20 47,5 120 5,3 20 rhs 4,0 2+1 10227915
20 56 130 5,3 20 rhs 4,0 2+1 10227922

Counterclockwise rotating tools with shank 20mm and threaded bore hole M6
D L2 L1 L3* Shank Rhs/ BH Z Order No. Price
mm mm mm mm mm lhs mm [PG 03]
16 37 105 5 20 lhs 3,5 2+1 10241987
20 47,5 120 5,3 20 lhs 4,0 2+1 10242006

Clockwise rotating tools with shank 25mm and threaded bore hole M8

D L2 L1 L3* Shank Rhs/ BH Z Order No. Price
mm mm mm mm mm lhs mm [PG 03]
16 29 100 5 25 rhs 3,5 2+1 10227899
16 37 105 5 25 rhs 3,5 2+1 10227894
20 30,5 100 5,3 25 rhs 4,0 2+1 10227908
20 39 110 5,3 25 rhs 4,0 2+1 10227913
20 47,5 120 5,3 25 rhs 4,0 2+1 10226388
20 56 130 5 25 rhs 4,0 2+1 10227923
25 22 90 5 25 rhs 3,5 2+1 10241982
25 30,5 100 5 25 rhs 5,0 2+1 10231710
25 39 110 5 25 rhs 5,0 2+1 10226251
25 47,5 120 5 25 rhs 5,0 2+1 10227946
25 56 130 5 25 rhs 5,0 2+1 10227948
25 73 140 5 25 rhs 5,0 2+1 10226530

Counterclockwise rotating tools with shank 25mm and threaded bore hole M8

D L2 L1 L3* Shank Rhs/ BH Z Order No. Price
mm mm mm mm mm lhs mm [PG 03]
25 47,5 120 5 25 lhs 5,0 2+1 10241994
