I DP shank cutter Z2 and Z3 Harmony

I Cutting 2.0

S Your benefits at a glance:
• Tear-free edges on the top coat • Ideally suitable for zero joint gaps and
• No tearing with transverse laser edge banding technology
edge banding • Extremely long tool life
• No multiple machining • Large variety of materials
L 1
Application: For sizing, grooving and jointing of wood-based panel material,
both with and without coating; especially suitable for chip Application: For sizing, grooving and jointing of wood-based panel
board with low density; very precise shank tolerances; thus material, both with and without coating; especially suitable
suitable for shrink clamping (recommended) suitable for L 2 for chip board with low density and front-end processing
plunge cutting and circular (helix) drilling L 3 of solid wood; very precise shank tolerances; thus suitable
D for shrink clamping (recommended); suitable for plunge
Material: Panel material with and without coating cutting and circular (helix) drilling (S20 = M6, S25 = M8)
Machine: Stationary machines with and without tool changer Material: Panel material with and without coating
Design: Ø 6 - 12,7 mm tool body of solid carbide Machine: Stationary machines with and without tool changer
Ø 16 – 25 mm tool body of steel
Design: Ø 16 - 25 mm tool body of steel; DP knives with extremely
DP knives with extremely large axial angle with up-cut and large axial angle with up-cut and down-cut design; for the
down-cut design; for the production of tear-free jointing edges production of tear-free jointing edges; asymmetrically
asymmetrically positioned knives suitable for rebates of up to positioned knives suitable for rebates of up to 12 mm height;
5 mm height the shank is threaded
Tooth: DP Tooth: DP
L3* = positive spin, cutting edge is pulling up L3* = positive spin, cutting edge is pulling up

D L2 L1 L3* Price
mm mm mm mm Shank Z Rhs/lhs Order No. [PG 03]
16 28 105 11 25 2+1 rhs 10206247
16 34 105 11 25 2+1 rhs 10206248
16 43 120 11 25 2+1 rhs 10206249
18 43 120 11 20 2+1 rhs 10206250
18 43 120 11 25 2+1 rhs 10206251
20 28 105 11 20 2+1 rhs 10206252
20 34 105 11 20 2+1 rhs 10206253
20 43 120 11 20 2+1 rhs 10206254
20 52 120 11 20 2+1 rhs 10206255
20 28 105 11 25 2+1 rhs 10206256
20 34 105 11 25 2+1 rhs 10195138
20 43 120 11 25 2+1 rhs 10206258
20 52 120 11 25 2+1 rhs 10196738
25 28 105 11 20 2+1 rhs 10206260
25 34 105 11 20 2+1 rhs 10206262
25 43 120 11 20 2+1 rhs 10206263
25 52 120 11 20 2+1 rhs 10206264
25 28 105 11 25 2+1 rhs 10196587
25 34 105 11 25 2+1 rhs 10206265
25 43 120 11 25 2+1 rhs 10206266
25 52 120 11 25 2+1 rhs 10206267
25 28 105 11 20 3+1 rhs 10206268
25 34 105 11 20 3+1 rhs 10206269
25 43 120 11 20 3+1 rhs 10206270
25 52 120 11 20 3+1 rhs 10206271
25 28 105 11 25 3+1 rhs 10194725
25 34 105 11 25 3+1 rhs 10206272
25 43 120 11 25 3+1 rhs 10206273
25 52 120 11 25 3+1 rhs 10206274
