I Accessories
I HP clamping system

Masterclamp for HSK 63
Accessories HP clamping system
Fast and safe mounting and clamping
The masterclamp is the perfect device for fast and safe
mounting of tools
Together with the hook wrenches or alternatively with the new torque
spanners, the Masterclamp is the perfect mounting aid for the HP collet
chuck

Price
for chucks Order No. [PG 02]
HSK 50 (SK 30) not for Morbidelli 10163754
HSK 63 (SK 40) 10163755

Standard hook wrench
Accessories HP clamping system

The proven hook wrench for clamping tools in the HP collet chuck and collet chuck with ball
bearing.

for D Price
Hook wrench type mm Collet Order No. [PG 02]
Hook wrench 52/55 462E 10180589
Combi-Hook wrench 53 & 58/62 462E 10203800
Hook wrench 50 ER 32 10006110
Hook wrench 30/32 ER 16 10205522

User-Tip:
The combi-hook wrench (standard and torque) fits for the HP- and also for standard-
collet chucks with ball bearing nut. You save yourself a hook wrench.

Torque spanner
Accessories HP clamping system

The torque spanners for safe clamping of tools in the HP collet chuck and collet chucks with ball
bearing

Torque spanner Hook wrench-Element

Torque Tool holder Nm Order Price Hook wrench-Element for D Collet Order No. Price
spanner mm No. [PG 02] for Typ 1 mm [PG 02]
Combination hook spanner key 53 & 58/62 462E 10203820
Type 1 14 x 18 60 - 320 10203818
Hook spanner key 50 ER 32 10203822

Torque Tool holder Nm Order Price Hook wrench-Element for D Collet Order No. Price
spanner mm No. [PG 02] for Typ 2 mm [PG 02]
Type 2 9 x 12 20 -120 10205397 Roller wrench 22 ER 16 Mini 10205399

383
