I DP disc type grooving cutter for Lamello P-System

Application: High performance disc-type crooving cutter for profile grooving
for connectors of the Lamello P-System
Material: Solid wood and wood-based materials with and without coating
Machine: Stationary machines

Design: Disc-type cutter to be mounted on circular saw blade holder;
Large chip spaces ensure the safe and smooth chip-removal
Tooth: DP cannot be re-sharpened,
the profile cannot be changed
Feed: MEC

B

d D

b

D B b d NL Z Cutting Order No. Price
mm mm mm mm material [PG 03]
4/6,6-13,0/48 cw
100,4 7,0 4,0 30 and 4/6,6-13,0/48 3 DP 10221871
counter cw
Further variants for mounting on aggregates with other pin holes available on request.

More tools for Lamello P-System:
Solid carbide shank cutter for Lamello P-System Order No. 10243271 Page 254
Solid carbide Through-hole drill Order No. 10232068 Page 327
Circular saw blade holders Page 403
HW disc grooving cutter for Lamello Zeta Order No. 9147C.100.03.22 blueline product programme
DP disc grooving cutter for Lamello Zeta Order No. 7147C.100.03.22 blueline product programme
