50010 I HW dowel drill with V tip
I for through-holes, 10 mm cylindrical shank,
I with back guidance

S Application: Drilling of through-holes in wood-based
material on dowel drilling machines and CNC machines
Design: Carbide cutting head, V tip with 60° angle; cylindrical shank
with clamping surface and adjustment screw; spiral part with
back guidance, plastic coated

L 1
L 2

D

D L2 L1 Shank Rhs / Price
mm mm mm mm Lhs Order No. [PG 02]
5 25 57,5 10x20 lhs 10022641
5 25 57,5 10x20 rhs 10022640
5 35 70,0 10x25 lhs 10022645
5 35 70,0 10x25 rhs 10022644

I Solid carbide step drill

Application: Pre-drilling for special thread inserts
S
in HPL/solid core
Design: Stable solid carbide base body; cylindrical shank;
two drill cutting edges with centre point

L
1

0,8 mm

D 2 L 2

D
1

D1 D2 L2 L1 Suitable S Rhs / Order No. Price
mm mm mm mm for mm Lhs [PG 02]
6,2 10,0 9 70 M4 10 rhs 10213840
7,5 11,0 9 70 M5 10 rhs 10170762
7,5 11,0 13 70 M5 10 rhs 10218543
1) 8,5 11,0 10 70 M6 10 rhs 10174081
9,5 13,0 9 70 M6 10 rhs 10170760
11,5 16,0 9 70 M8 10 rhs 10170759
1) Step drill for special thread insert for HPL/solid core on the panel edges
