Real-Time-Analyser

High resolution standard microscopes and special microscopes

High resolution standard microscopes and special microscopes

Microscope 5 Megapixel with automatic magnification transfer (included in the Advanced variant)

This is our premium optics for the Advanced variant of the RTA. The microscope features a resolution of 5 Megapixel
and is therefore sharp to the last detail. Moreover, the microscope is equipped with an automatic magnification
transfer.
The specific feature is: the magnifier transfers the current zoom level automatically to the measuring software.
Reading of the current zoom level and manually entering the value in the software is not necessary. Measuring
operations can thus be carried out even more quickly and with maximum precision.
The optics is suitable for visualizing as well as measuring operations and thus a good choice for demanding
applications. This optics unit is, of course, also available as an accessory – very practical if you want to upgrade
your Basic variant.

Microscope 1.3 Megapixel (included in the Basic variant)
Our strong optical unit for the Basic variant. The microscope has a resolution of 1.3 Megapixel and therefore provides
high-resolution pictures. It is particularly suitable for visualising or plausibility measurements. This magnifier is also
included in our list of accessories – in case you want to get yourself, for example, a freehand magnifier.

Microscope for large free working distance and automatic magnification transfer

With this microscope even those angles which require a front view on the tooth face can be measured. These are,
for example, the radial clearance angle and the bevel angle. For this purpose the microscope is to be positioned at
the outer mounting position of the RTA (< Ø 350 mm).
The tooth face can now be focused and the measuring operations carried out as usual. The optics moreover
possesses an automatic magnification transfer for easy handling. It provides high-resolution pictures for a brilliant
display. Combined with the microscope holder „long“ this function is also available for saw blades with diameters of
more than 350 mm.

Microscope with up to 470x magnification

A 200x magnification is not sufficient for your application? In that case turn to this one and utilize the huge zoom of up
to 470-fold. You will then make a mountain out of each dust speck. This microscope has a resolution of 5 Megapixel
and works with a zoom level of 400x - 470x. Maximum magnification for your work!

Microscope with enhanced depth of sharpness

You are looking for images with maximum richness of detail? With this microscope you are taking one step forward
approaching this target. Whenever you take a photo a very specific technology is being used: Several photos are
(automatically) produced in different zoom levels and put on top of each other. This is how you get a final image with
enhanced depth of sharpness and greater richness of detail. The applied optics provides a high resolution.
