Real-Time-Analyser

Basic systems and variants

Variant of „Basic“

The image shows an RTA-L of the „Basic“ variant. In front you see the accessories (from left to right): Saw blade
support, centring pin, 1.3 MP optics mounted in the microscope holder and the saw blade fixation.

Variant of „Advanced“

The image shows an RTA-L of the „Advanced“ variant. In front you see the accessories (from left to right): Analysing
table, saw blade support, centring pin, swivelling support plate, 5.0 MP optics with automatic magnification transfer
mounted in the microscope holder, saw blade fixation as well as analysing prism.
