Aluminium
0020DA I Circular saw blade for aluminium
I Bombastic

Your benefits at a glance:

BOMBASTIC -
Synonym for excellent cuts
Application: Finish cut in homogeneous material The synonym for excellent cuts – forget about subsequent reworking of edges.
Designed for cutting non-ferrous metal the Bombastic circular saw blade generates
Recommendation: use emulsion as a coolant substantial cost savings due to several times‘ service life. Reworking becomes
Material: Thermoplastics: PC, PMMA dispensable particularly wherever aluminium profiles are being cut.
Machine: Panel sizing machine
Almost burr-free cutting edges
Design: Type A: Thermoplastics, thin-walled, low tensile strength • Optimal cuts on your finished product due to
of max. 50-60 N/mm² specifically ground tooth geometries
Type C: Thermoplastics, for stacks of material, tensile • Higher cutting quality
strength > 50 N/mm² Extremely long service life
Tooth: Type A: Alternate top bevel tooth chamfered (WS), HW • Several times‘ service life compared to
standard saw blades
Type C: Triple-chip - triple-chip tooth (TT), HW • Low vibration
Feed: MEC Hardly any re-machining necessary
• No subsequent de-burring
• Shorter cycle time

Application: Cross cut in profiles, finish processing
Material: Aluminium alloys, anodised, profiles of up to
10 mm wall thickness, profiles of non-ferrous metal
Machine: Mechanic cross-cut saws, flush-mounted cross-cut
saws, machining centre with sawing aggregate,
revolving transfer machine, continuous casting plants
Design: Type DA; • = riveted - thus very quiet and
vibration-free cutting results
Tooth: Triple-chip flat tooth (FT), HW
Feed: MEC

D B b d Type Z Tooth Order No. Price
mm mm mm mm shape [PG 03]
250 2,80 2,00 30 DA 80 FT 0020.250.30
300 3,00 2,20 30 DA 96 FT 0020.300.30
350 3,60 3,00 30 DA 96 FT 0020.350.30
400 3,80 3,00 30 DA 96 FT 0020.400.30
450 4,00 3,40 30 DA 102 FT 0020.450.30
500 4,20 3,40 30 DA 96 FT 0020.500.31
500 4,00 3,40 30 DA 120 FT 0020.500.30
550 4,20 3,40 30 DA 132 FT 0020.550.30
600 4,80 4,00 30 DA 138 FT 0020.600.30
When ordering, please specify pin holes, flange diameter and number of revolutions
All dimensions available from Ø 160 to 800 mm on the basis of your machine specification
