Hogger 0032 I Spare circular saw blade for hogger

I Suitable for AKE segment hogger

Application: For sizing panel material
Material: Wood-based material, raw and coated
Machine: Double-end profiler and edge bander
Design: HW saw blade (flat tooth); tooth geometries can be
optimized according to customer’s request
Pin hole countersinking Ø 10.5 mm
lhs = countersinking top counter clockwise,
rhs = countersinking top clockwise
Fig.: Right-hand design Tooth: Flat tooth (F), HW
Feed: MEC

15°

10°
Fig.: AKE Segment Fig.: AKE Segment Fig.: Spare hogger
hogger Type 0033 hogger Type 0034 segment

Fine-cut saw blade [0032] for AKE segment hogger [0033], 10.5 mm countersunk (lhs = top counter CW, rhs = top CW)
D B b d NL Z Tooth Rhs/ Order No. Price
mm mm mm mm mm shape Lhs [PG 01]
205 4,00 2,80 80 4/6/140 44 F lhs 0032.201.01
205 4,00 2,80 80 4/6/140 44 F rhs 0032.202.01
205 4,00 2,80 80 4/6/140 60 F lhs 0032.203.01
205 4,00 2,80 80 4/6/140 60 F rhs 0032.204.01
255 4,00 2,80 80 6/6/190 48 F lhs 0032.251.02
255 4,00 2,80 80 6/6/190 48 F rhs 0032.252.02
255 4,00 2,80 80 6/6/190 60 F lhs 0032.253.02
255 4,00 2,80 80 6/6/190 60 F rhs 0032.254.02

Fine-cut saw blade [0032] for AKE segment hogger [0034], 10.5 mm countersunk (lhs = top counter CW, rhs = top CW)
D B b d NL Z Zahnform Rhs/ Order No. Price
mm mm mm mm mm Lhs [PG 01]
205 4,00 2,80 80 4/6/140 44 F lhs 0032.201.01
205 4,00 2,80 80 4/6/140 44 F rhs 0032.202.01
205 4,00 2,80 80 4/6/140 60 F lhs 0032.203.01
205 4,00 2,80 80 4/6/140 60 F rhs 0032.204.01
255 4,00 2,80 100 6/6/190 48 F lhs 0032.255.01
255 4,00 2,80 100 6/6/190 48 F rhs 0032.255.02
255 4,00 2,80 100 6/6/190 60 F lhs 0032.255.03
255 4,00 2,80 100 6/6/190 60 F rhs 0032.255.04

Spare segment for AKE segment hogger
Denomination Order No. Price
[PG 01]
HW segment with chip breaker, with threaded pin 1 VE (= 12 pcs.) 0033.012.01

106
