Wood-based
circular
0024 saw blade

Circular panel sizing saw blade
Panel sizing

APPLICATION: Panel sizing. Single cut or in packs

MATERIAL: Plastic laminated and film-coated wood-based material
Duroplast

MACHINE: Panel sizing machine horizontal with scoring aggregate

DESIGN: Rigid saw body,
♪=Soundstar design: noise reduced
•=with copper plugs

TOOTH: Triple-chip / flat tooth (FT), HW
0024 FEED: MEC

Continued from previous page.
B
NL
d
b
D
0,4 mm mm mm mm mm Machine Z Order No.
15° 45°
• 380 4,40 3,20 60 2/14/100+2/14/125 Holzma 72FT 002438060
• 380 4,40 3,20 65 2/9/110 Selco 72FT 002438065
15° • 380 4,40 3,20 80 2/14/1110 Gabbiani 72FT 002438080
• 380 4,80 3,50 60 2/14/100 + 2/14/125 Holzma 72FT 002438160
• 380 4,80 3,50 60 2/14/100 + 2/14/125 Holzma 84FT 002438161
• 380 4,80 3,50 60 2/14/100 + 2/14/125 Holzma 96FT 002438163
• 400 4,40 3,20 30 Panhans, 60FT 002440031
Scheer
• 400 4,25 3,20 30 2/10/60 Scheer 72FT 002440003
• 400 4,40 3,20 30 2/10/60 Mayer, Scheer 72FT 002440030
Panhans,
♪ 400 4,40 3,20 30 2/10/60 Mayer, Scheer 72FT 012440030
Panhans,
400 4,40 3,20 30 KS 72FT 002440230
• 400 4,40 3,20 60 2/11/85 Anthon 72FT 002440060
• 400 4,40 3,20 75 4/15/105 Giben 72FT 002440075
• 400 4,40 3,20 80 4/8,5/100 + 2/7/110 + Gabbiani 60FT 002440083
2/14/110
• 400 4,40 3,20 80 4/19/120 + 2/9/130 Selco 72FT 002440080
• 420 4,40 3,20 80 2/14/110 Gabbiani 72FT 002442080
• 420 4,60 3,20 60 2/19/120 + 2/14/125 Holzma 72FT 002442060
• 420 4,80 3,50 60 2/14/125 + 2/19/120 Holzma 72FT 002442160
• 420 4,80 3,50 60 2/14/125 + 2/19/120 Holzma 84FT 002442161
430 4,40 3,20 30 72FT 002443030
430 4,40 3,20 65 2/9/110 Selco 72FT 002443065
430 4,40 3,20 75 4/15/105 Giben 72FT 002443077
430 4,40 3,20 75 4/15/105 Giben Prismatic 96FT 002443075
430 4,80 3,50 70 4/11/130 Selco 72FT 002443070
430 4,40 3,20 60 2/11/85 Anthon 72FT 002443060
430 4,40 3,20 80 2/9/130 + 4/19/120 Selco 72FT 002443080
450 4,40 3,20 30 54FT 002445031
Mayer, Pan-
450 4,40 3,20 30 2/10/60 hans, Scheer, 72FT 002445030
Schelling
450 4,40 3,20 80 KS 72FT 002445080
450 4,40 3,20 80 4/8,5/100 + Gabbiani 72FT 002445081
2/7/110+2/14/110
450 4,40 3,20 80 2/9/130 + 4/19/120 Selco 72FT 002445082
• 450 4,80 3,50 30 2/8,5/60 Scheer 72FT 002445032

Continued next page.
