I Screws

Price
Denomination Dimension Key size Order No. [PG 02]
mm
Threaded pin DIN 912 for swivelling cutter head M5 x 16 10030678
Threaded pin DIN 912 for swivelling cutter head M6 x 8 10015777
Threaded pin DIN 915 M8 x 16 SW 6 40002009
Threaded pin DIN 915 M8 x 35 SW 6 40002014
Fig: Threaded pin DIN 915

Price
Denomination Dimension Key size Order No. [PG 02]
mm
Countersunk screw DIN 963 M5 x 8 Slot 40001969
Countersunk screw DIN 963 M5 x 6 Slot 10119194
Countersunk screw DIN 7991 M5 x 6 SW 4 40001968
Countersunk screw DIN 7991 T M5 x 6,1 T 20 40005305
Fig: Countersunk screw DIN 963

Fig: Countersunk screw DIN 7991

Price
Denomination Dimension Order No. [PG 02]
mm
Stop screw M5 40002938

Fig: Stop screw

418
