Wood-based material MEC

0026 I HW / DP scorer for
7026 I applicable for all Boardline-main blades

Benefits of the 0026B:

• +40% re-sharpenings • innovative tooth design: S02+
• longer service life • up to 17 regrinding cycles

Application: Scoring of wood-based material in feed direction
DP design for max. tool life and low costs per cut;
HW design for low initial costs
Material: Wood-based material coated and uncoated,
HPL, Multiplex
Machine: Panel sizing unit horizontal with scoring aggregate
Tooth: Flat tooth conical (F con.), Alternate top bevel tooth (W),
HW / DP
Feed: MEC

Fig.: Flat tooth conical (F con.) Fig.: Aternate top bevel tooth (W)

D B b d NL Machine Z Tooth Order No. Price Type D B b d NL Z Tooth Order No. PG Price
mm mm mm mm mm shape [PG 5A] mm mm mm mm mm shape
HW Scoring saw blade 200 5,0-5,8 3,50 20,0 2/11/66 36 F con. 0026B.200.36.20-B50 5A
530 5,00 3,50 30 Schelling 60 FT 0024B.530.60.30 HW Scoring saw blade 200 5,4-6,2 3,50 20,0 2/11/66 36 F con. 0026B.200.36.20-B54 5A
DP Scoring saw blade 200 5,0-5,8 3,50 20,0 2/11/66 32 F con. 7026.200.22 03
HW Scoring saw blade 180 5,8-6,6 4,00 20,0 36 F con. 0026B.180.36.20-B58 5A
530 5,80 4,00 60 2/11/85 Anthon 60 FT 0024B.530.60.60
HW Scoring saw blade 180 6,2-7,0 4,00 20,0 36 F con. 0026B.180.36.20-B62 5A
HW Scoring saw blade 200 4,8-5,6 3,50 45,0 36 F con. 0026B.200.36.45-B48 5A
HW Scoring saw blade 200 5,2-6,0 3,50 45,0 36 F con. 0026B.200.36.45-B52 5A
570 4,80 3,50 60 2/14/100 + 2/11/115 + Homag SAWTEQ B-500 60 FT 0024B.570.60.60 HW Scoring saw blade 200 4,6-5,6 3,50 45,0 36 W con. 0026.200.38 5A
2/19/120 + 2/14/125
(HPP 500)
DP Scoring saw blade 200 4,8-5,6 3,50 45,0 32 F con. 7026.200.46 03
HW Postforming 340 5,00 3,50 45,0 3/14/65 108 W 0026.341.49 5A
HW Scoring saw blade 200 5,5-6,3 4,00 20,0 2/11/66 36 F con. 0026B.200.36.20-B55 5A
580 5,50 4,00 40 2/13/114 + 2/13/122 + Schelling AT & FT & AS & FS 60 FT 0024B.580.60.40 HW Scoring saw blade 200 5,9-6,7 4,00 20,0 2/11/66 36 F con. 0026B.200.36.20-B59 5A
2/13/140
DP Scoring saw blade 200 5,5-6,4 4,00 20,0 2/11/66 32 F con. 7026.200.23 03
HW Scoring saw blade 200 5,8-6,6 4,00 45,0 36 F con. 0026B.200.36.45-B58 5A
600 5,80 4,00 60 2/14/100 + 2/11/115 + Homag SAWTEQ B-600 60 FT 0024B.600.60.60 HW Scoring saw blade 200 6,2-7,0 4,00 45,0 36 F con. 0026B.200.36.45-B62B 5A
(HPP 600)
2/19/120 + 2/14/125
DP Scoring saw blade 200 5,8-6,6 4,50 45,0 32 F con. 7026.200.47 03
HW Scoring saw blade 200 5,8-6,6 4,00 45,0 36 F con. 0026B.200.36.45-B58 5A
600 5,80 4,00 60 2/14/100 + 2/11/115 + Homag SAWTEQ B-600 72 FT 0024B.600.72.60 HW Scoring saw blade 200 6,2-7,0 4,00 45,0 36 F con. 0026B.200.36.45-B62B 5A
2/19/120 + 2/14/125
(HPP 600)
DP Scoring saw blade 200 5,8-6,6 4,50 45,0 32 F con. 7026.200.47 03
HW Scoring saw blade 200 6,2-7,0 4,20 20,0 2/11/66 36 F con. 0026B.200.36.20-B62 5A
620 6,20 4,20 40 2/13/114 + 2/13/140 Schelling ATH (FTH) 60 FT 0024B.620.60.40 HW Scoring saw blade 200 6,6-7,4 4,20 20,0 2/11/66 36 F con. 0026B.200.36.20-B66 5A
DP Scoring saw blade 200 6,2-7,0 4,20 20,0 2/11/66 32 F con. 7026.200.25 03
HW Scoring saw blade 200 7,0-7,8 5,00 20,0 2/9/60 36 F con. 0026B.200.36.20-B70 5A
700 7,00 5,00 80 2/17/110 Anthon LNC 60 FT 0024B.700.60.80 HW Scoring saw blade 200 7,4-8,2 5,00 20,0 2/9/60 36 F con. 0026B.200.36.20-B74 5A
DP Scoring saw blade 200 7,0-7,8 5,00 20,0 2/9/60 32 F con. 7026.200.27 03
HW Scoring saw blade 220 6,4-7,2 4,40 20,0 36 F con. 0026B.220.36.20-B64 5A
720 6,40 4,40 40 2/13/114 + 2/13/122 + Schelling AS & FS 60 FT 0024B.720.60.40 HW Scoring saw blade 220 6,8-7,6 4,40 20,0 36 F con. 0026B.220.36.20-B64 5A
2/13/140
DP Scoring saw blade 220 6,4-7,2 4,40 20,0 32 F con. 7026.220.20 03
