The RTA is precise, easy to operate, reliable and 100% workshop-compatible.
With these features, it has become an integral part of the process controls at AKE.
We want to give you the opportunity to benefit from our experience and to check tools in
the same way as we do.

Discover the versatile application possibilities:

Tangential clearance angle
= 3,91 °

Offset top
L=0,76 mm
Tooth centre
Offset below L=2,13 mm Cutting width
L=0,70 mm L= 3,53 mm

Cutting width Tangential clearance angle
L=4,26 mm = 3,95 °

Example measurement flat fraction Example clearance angle measurement

Real-Time-Analyser
Name Angle Length Radius Diameter
Angle 1 16,11 - - -
Angle 2
Angle 2 11,34 - - -
= 11,34°

Angle 1
= 16,11°

Easy export of the measured data to Excel: Creation of measurement protocols for quality assurance for you and your customers

Contact us and configure „your“ RTA!

Your grinding quality becomes tangible.
with the RTA
